​As the linchpin of artificial snow production in ski resorts, snowmaking machines are crucial for ensuring high – quality snow cover and maintaining optimal ski slope conditions. This snowmaking plan details an efficient approach, covering both the technical operation of these machines and practical usage guidelines.​

The snowmaking machine operates on the principle of “water droplet freezing.” It employs a high-pressure water pump to elevate water pressure to 10-15 MPa, atomizing it into minuscule droplets, measuring 50-100 microns in diameter, through specialized nozzles. Concurrently, a fan generates a high-velocity airflow to propel these atomized droplets into the atmosphere. When the ambient temperature drops below -2°C and the relative humidity is below 80%, the droplets encounter frigid air during their descent, rapidly freezing to form ice crystals—artificial snow. Advanced models are fitted with nucleators that release refrigerants to produce “seed ice crystals,” enabling snow production even in suboptimal conditions as warm as -1°C, thus enhancing environmental versatility.​

The implementation of usage specifications shall adhere to the “three priorities” principle.​

1.Pre – startup Equipment Inspection​

Conduct a meticulous pre – operation check of all components. Ensure that water pipes are free of ice accumulation, nozzles are unobstructed, the fan and water pump are in proper working condition, and the hydraulic system pressure remains stable within the specified range.​

2.Optimal Snowmaking Timing Selection​

Prioritize snowmaking during low – temperature nighttime hours and avoid adverse weather conditions such as strong winds or rain to maximize efficiency and maintain snow quality. When commencing operations, initiate the fan first and allow it to preheat for 3 minutes before activating the water pump for water supply.​

3. Dynamic Parameter Adjustment​

Adjust water pressure and air volume according to ambient temperature. As a general rule, lower temperatures allow for a proportional increase in water pressure, enhancing the density of atomized droplets. In the event of strong winds, boost the fan power to ensure even dispersion of snow particles across the ski resort area.​

During operation, implement real-time monitoring: utilize a snow quality sensor to accurately detect the moisture content of snow particles, maintaining it within the optimal range of 8% to 12%. This ensures that the produced snow avoids the formation of “wet snow” or overly dry “powder snow”. Adjust the snowmaking angle based on the specific requirements of the ski slope: for the main ski runs, adopt horizontal spraying; in the buffer zones, elevate the nozzles to effectively increase the snow layer thickness. After the snowmaking machine is shut down, thoroughly drain all residual water from the equipment, turn off the main power supply and water source, and apply comprehensive anti-freezing protection measures to safeguard the equipment.​

By leveraging a scientific understanding of the snowmaking machine’s operational principles and adhering to standardized procedures, high-quality artificial snow can be efficiently generated under optimal environmental conditions. This approach not only guarantees the snow quality on ski slopes but also extends the operational lifespan of the ski resort.
